Varjena žična mreža: plošče, role in paneli iz nerjavnega jekla – varnost, trajnost, eleganca
Večina žičnih mrež in panelnih ograj, ki se uporabljajo v industriji, gradbeništvu in drugih področjih, je izdelanih iz navadnega nizkoogljičnega jekla. Takšni materiali so dovzetni za korozijo in zahtevajo protikorozijsko zaščito. Običajno se po izdelavi varjene mrežne plošče barvajo, pocinkajo ali prevlečejo s plastiko. Vsaka prevleka ima svoje pomanjkljivosti in je primerna le za domačo uporabo.
Izdelki iz nerjavnega jekla niso podvrženi koroziji in ne zahtevajo dodatnega vzdrževanja.
Varjene mrežne plošče se uporabljajo v živilski industriji, kemični industriji in v vsakdanjem življenju — odporne so na agresivna okolja, morsko vodo in stik z zemljo. Varjene žične mreže v roli prenesejo temperature do 1000 °C in se ne bojijo odprtega ognja. Izdelane so iz nerjavnega jekla kakovosti za živila 18/10 (AISI 304) — zato so popolnoma varne pri stiku z živili.
Proizvodnja, značilnosti in standardi varjenih mrežnih plošč
To so mreže s pravokotnimi (večinoma kvadratnimi) odprtinami, kjer so žice med seboj spojene s tlačnim varjenjem (točkovnim varjenjem).
Varjene plošče se proizvajajo v skladu z naslednjimi standardi:
- ISO 14315 »Izdelava žičnih mrež — tehnične zahteve in preskušanje«
- ISO 4783-3 »Industrijske žične plošče in tkane mreže — vodnik za izbiro kombinacij velikosti odprtin in premerov žic — del 3: priporočene kombinacije za prednapete ali tlačno varjene mreže«
- ASTM F2453 »Standardna specifikacija za varjeno žično mrežno tkanino (kovinsko ali polimerno prevlečeno) za mreže z odprtinami 6 in² [3871 mm²] ali manj, v ploščah ali kolutih, z enotnimi mrežami«
- ASTM F2919 »Standardna specifikacija za varjeno žično panelno tkanino (kovinsko ali polimerno prevlečeno) z različnimi vzorci mrež ali z odprtinami večjimi od 6 in² [3871 mm²], v ploščah«
Kako kupiti varjeno mrežo na Poljskem in v EU
Varjene plošče iz nerjavne jeklene žice kakovosti AISI 304 (X5CrNi18-10, 4301-304-00-I, EN 1.4301) so na voljo tako iz zaloge kot po posebnem naročilu, kar zagotavlja prilagodljivost za stranke po vsej Evropi. Te plošče so izdelane z visoko natančnostjo v skladu s strogimi industrijskimi standardi, zato so primerne za širok spekter uporabe. Kupci, ki iščejo zanesljivega dobavitelja, lahko obiščejo naše skladišče v Łódźu (Poljska) ali uredijo neposredno dostavo znotraj EU.
Velikost in oblika dobave žične mreže od dobavitelja
Te žične mreže se dobavljajo v kolutih ali ploščah:
- izdelane iz žice s premerom 3,0 mm ali več (odprtine 20×20 mm ali več) — v ploščah (kartah) velikosti 1000×2000 mm;
- izdelane iz žice s premerom 2,5 mm ali manj (s celicami 25×25 mm ali manj) — v rolah širine 1000 mm.
Technical parameters of stainless steel welded wire mesh panels
Technical parameters are selected according to working conditions, loads and hygienic requirements. The wire diameter, opening size and surface finishing method are important.
Wire-Mesh offers stainless steel welded mesh panels. They are produced in sheets and rolls. The openings have different dimensions. They start from small sizes of 10x10 mm. Larger meshes are used for technological partitions and protection systems.
Surface finish: raw, pickled, and electro-polished mesh
Stainless steel welded wire mesh has different surface finishes. This depends on its application. Raw versions are most often used in construction and technical structures.
Chemical pickling removes impurities after processing. It also improves corrosion resistance. It is used mainly in the food, pharmaceutical and laboratory industries. There, high hygiene and easy cleaning matter.
Influence of wire diameter on construction rigidity
A thicker wire makes stainless steel welded mesh stronger. It better withstands deformation and mechanical loads. Wires from 1 to 2 mm thick are used for light guards and filtration. Industrial structures often require wires from 3 to 5 mm. When designing, the proportion between the opening size and the wire thickness should be taken into account. A wire that is too thin and a large opening weaken the stability of the structure.
Versatile applications of stainless steel welded mesh in industry
Stainless steel welded mesh panels are used in industry, construction and agriculture. They are corrosion-resistant, and their parameters can be adapted.
Hygiene and safety: food, pharmaceutical, and processing industries
Stainless steel welded mesh has a PZH certificate. It is suitable for use in places where it will have direct contact with food. The smooth surface of the steel limits the accumulation of dirt. That is why the stainless steel welded wire mesh panel is used in machine guards, production lines, dryers and separators.
Architecture, construction, and modern design – from balustrades to facades
Modern construction often uses stainless steel. It has decorative and structural applications. Welded wire mesh stainless steel is used in balustrades, ventilated facades, protective panels and modern fences.
An important advantage is the production of sheets with non-standard dimensions. This reduces the amount of waste during installation. It also shortens the project completion time.
Breeding and agriculture – durable aviaries and weather-resistant cages
Acid-resistant stainless steel welded mesh is used in aviaries, breeding cages and for protecting infrastructure, because it withstands moisture and weather changes.
Solutions for the HVAC industry and filtration systems
In ventilation and filtration systems, dimensional stability and moisture resistance are important. Welded wire meshes stainless steel serve as filter elements, ventilation duct guards and separators.
In specialized industrial filters, woven copper mesh is also used. It is valued for its good conductivity and electromagnetic shielding.
Care and maintenance – how to maintain stainless steel properties?
Stainless steel is very durable. However, it needs basic maintenance. Regular cleaning of deposits, industrial dust and organic impurities helps maintain the properties of the protective layer.
For cleaning, use products for stainless steel. Avoid contact with aggressive agents containing chlorine. In places with higher salinity, it is recommended to inspect the surface from time to time.
Wire-Mesh as a stainless steel welded mesh supplier – quality guarantee and price
Wire-Mesh, a stainless steel welded mesh supplier, controls quality. It also offers parameter customization and deliveries throughout EU.
Quality control and material certification
We attach material documentation to each welded wire mesh stainless steel. This confirms compliance with PN-EN 10088 standards. Quality control verifies the wire diameter, opening dimensions and weld quality.
We offer solutions that meet hygienic requirements. PZH documentation can be obtained for them.
Stainless steel welded mesh price – what determines the cost per square meter?
The price of stainless steel welded mesh 316 is higher than that of 304. This is because it contains molybdenum and is more chemically resistant.
The current nickel quotation on the LME, London Metal Exchange, is also important. This directly determines stainless steel prices in Europe.
How to order the right mesh at Wire-Mesh? Logistics and transport
When placing an order, indicate the steel grade, wire diameter, opening size, sheet or stainless steel welded wire mesh roll format, as well as the intended application. This helps choose the parameters. Thanks to them, the product is durable and safe in use. If the ordered product is a stainless steel welded wire mesh panel, it is also worth specifying the requirements regarding corrosion resistance.
Wire-Mesh delivers products throughout EU and can manufacture custom formats, which reduces material losses during installation. Protection during transport reduces the risk of surface damage.
FAQ – Frequently asked questions about stainless steel welded wire mesh rolls
Answers to the questions most frequently asked by designers, contractors and purchasing departments when choosing technical materials.
Cena varjene mreže iz nerjavnega jekla je v veliki meri odvisna od njene velikosti in teže na kvadratni meter. Na spletni strani je predstavljen cenik varjenih žičnih mrež, ki so stalno na zalogi. Pri izdelavi mrež v kolutih z drugačnimi odprtinami ali iz žice drugega premera se cene izračunajo individualno.
